Product Image

Diameter (mm) Suction x Discharge 80×80
Maximum head (m) 32
Maximum flow capacity (L/min) 1000
Packing dimension (mm, L x W x H) 545×410×485
Gross weight(kg) 30~31
Engine Hose power(PS) 4.9~6.3
Engine manufacturer MEiKi Power 、Honda
The photo shows:Honda engine mounted.



  • Washing of agricurtural/construction equipments or vehicles.
  • General farming liquid fertilizing.
  • Irrigation, transfer water & pumping shallow well water.
  • Water Supply to Water tank reserver.


  • The most popular pump in hundreds of applications in agricultural fields,the 3 Inch of ours, is suppliable with the highest quality Japanese engines. You can choose any out of Honda, MEiKi Power, Yamaha, Kubota engines, for better fuel economy,lowest emissions, easy parts availability, as well as for longer life.
  • Discharge direction can be adjusted by every 90 degrees.
  • A different size of outlet port (1.5 Inch, 2Inch,2.5Inch & 3Inch) is available to fit, as well as variation of suction port changeable to 1.5Inch, 2Inch & 3Inch.
